B1 Series Platinum-Plated Plug-in Connector
The B1 Series Platinum-Plated connector — the plug half of the B1 interface — is supplied in white / grey-green. The B1 is the heavy-duty option in the range. The two power contacts are platinum-plated, which keeps contact resistance low and resists the oxidation that builds up on unplated contacts after repeated mating.
- Matched plug-in connector for high-power handpieces where contact resistance and heat build-up matter
- Keyed shell — mates one way only, no reversed insertion
- Multi-pin signal block + platinum-plated power contacts carried in a single mated pair
- White / Grey-green housing; flexible or rigid hose
- OEM colour, logo and pin-out options on request
Request quotation for KMD-B1-PT
Or send the mating-socket photo to info@kmdconnector.com — we confirm the variant before you order.
Overview
The B1 Series Platinum-Plated connector — the plug half of the B1 interface — is supplied in white / grey-green. The B1 is the heavy-duty option in the range. The two power contacts are platinum-plated, which keeps contact resistance low and resists the oxidation that builds up on unplated contacts after repeated mating.
It is used on high-power handpieces where contact resistance and heat build-up matter, such as laser and intense-light systems. Platinum plating is chosen for the power path rather than the signal pins: it is where current density and wear are highest, and where a rising contact resistance shows up first as a hot connector or a dropped output. Buyers specify it when a connector is the weak point in a high-current handpiece and they want a longer service interval between replacements.
Order it together with its mating half — B1 plugs and handpiece-end connectors are sold as a matched pair, so keying and pin-out always line up.
Specifications
| Model | KMD-B1-PT |
|---|---|
| Series | B1 |
| Type | Plug-in connector |
| Pin configuration | multi-pin signal block + platinum-plated power contacts |
| Housing colour | White / Grey-green |
| Tail / hose | flexible or rigid hose |
| Mating half | B1 handpiece-end |
| Certification | CE / RoHS / UL |
| MOQ | 200 pcs (OEM) · 50 pcs (distributor) · 5 pcs (repair) |
| Lead time | 15 working days after deposit |
Frequently asked questions
Which machines does this connector fit?
It is designed for high-power handpieces where contact resistance and heat build-up matter, such as laser and intense-light systems. Interface compatibility depends on the pin-out and keying of your handpiece, so send us a photo of the mating socket or the machine model before ordering; we will confirm the match in writing.
Is this a complete connector or half of a pair?
This listing is the plug half. The mating handpiece-end half is a separate part number; order both for a guaranteed keyed pair.
Can you supply samples before a bulk order?
Yes. Samples are available for evaluation, and the sample cost is normally credited against the first production order.
Can the colour, logo or pin-out be customised?
Housing colour and laser marking are tooling-dependent and can be quoted; pin-out changes require a minimum quantity because they change the contact block.
What is the MOQ and lead time?
Both depend on the series and configuration. Send your annual volume and target date and we will return a firm quotation with a production schedule.
