D1 Series Compact Plug-in Connector
The D1 Series Compact connector — the plug half of the D1 interface — is supplied in black / white. The D1 is the small-format plug in the D family. It keeps the keyed shell and the split between power contacts and signal block, but in a narrower body that fits slim handpiece tails.
- Matched plug-in connector for compact handpieces and entry-level platforms where connector size and cost both matter
- Keyed shell — mates one way only, no reversed insertion
- Multi-pin signal block + power contacts carried in a single mated pair
- Black / White housing; flexible hose
- OEM colour, logo and pin-out options on request
Request quotation for KMD-D1-BW
Or send the mating-socket photo to info@kmdconnector.com — we confirm the variant before you order.
Overview
The D1 Series Compact connector — the plug half of the D1 interface — is supplied in black / white. The D1 is the small-format plug in the D family. It keeps the keyed shell and the split between power contacts and signal block, but in a narrower body that fits slim handpiece tails.
It is used on compact handpieces and entry-level platforms where connector size and cost both matter. A short mating travel and a simple latch make it quick to connect, while the keying still prevents a reversed insertion. It is the volume part: the one specified on high-run production models where the connector is not the design constraint.
Specify the pair by series, not by part: D1 plugs and handpiece-end connectors are checked as a set before packing.
Specifications
| Model | KMD-D1-BW |
|---|---|
| Series | D1 |
| Type | Plug-in connector |
| Pin configuration | multi-pin signal block + power contacts |
| Housing colour | Black / White |
| Tail / hose | flexible hose |
| Mating half | D1 handpiece-end |
| Certification | CE / RoHS / UL |
| MOQ | 200 pcs (OEM) · 50 pcs (distributor) · 5 pcs (repair) |
| Lead time | 15 working days after deposit |
Frequently asked questions
Which machines does this connector fit?
It is designed for compact handpieces and entry-level platforms where connector size and cost both matter. Interface compatibility depends on the pin-out and keying of your handpiece, so send us a photo of the mating socket or the machine model before ordering; we will confirm the match in writing.
Is this a complete connector or half of a pair?
This listing is the plug half. The mating handpiece-end half is a separate part number; order both for a guaranteed keyed pair.
Can you supply samples before a bulk order?
Yes. Samples are available for evaluation, and the sample cost is normally credited against the first production order.
Can the colour, logo or pin-out be customised?
Housing colour and laser marking are tooling-dependent and can be quoted; pin-out changes require a minimum quantity because they change the contact block.
What is the MOQ and lead time?
Both depend on the series and configuration. Send your annual volume and target date and we will return a firm quotation with a production schedule.
