D4 Series 12-Pin Plug-in Connector
The D4 Series 12-Pin connector — the plug half of the D4 interface — is supplied in white. The D4 carries a twelve-position signal block alongside the power contacts. The blue latch gives a positive lock with a visible release, so the state of the connection is readable at a glance.
- Matched plug-in connector for handpieces that need a high signal count
- Keyed shell — mates one way only, no reversed insertion
- 12 signal + power contacts carried in a single mated pair
- White housing; flexible or rigid hose
- OEM colour, logo and pin-out options on request
Request quotation for KMD-D4-12P
Or send the mating-socket photo to info@kmdconnector.com — we confirm the variant before you order.
Overview
The D4 Series 12-Pin connector — the plug half of the D4 interface — is supplied in white. The D4 carries a twelve-position signal block alongside the power contacts. The blue latch gives a positive lock with a visible release, so the state of the connection is readable at a glance.
It is used on handpieces that need a high signal count, such as multi-function platforms with sensors and feedback. Twelve signal positions allow separate runs for sensing, feedback and control instead of multiplexing them onto a few wires. It is specified when a handpiece reports more than a simple on/off state and the cable cannot grow another connector.
Order it together with its mating half — D4 plugs and handpiece-end connectors are sold as a matched pair, so keying and pin-out always line up.
Specifications
| Model | KMD-D4-12P |
|---|---|
| Series | D4 |
| Type | Plug-in connector |
| Pin configuration | 12 signal + power contacts |
| Housing colour | White |
| Tail / hose | flexible or rigid hose |
| Mating half | D4 handpiece-end |
| Certification | CE / RoHS / UL |
| MOQ | 200 pcs (OEM) · 50 pcs (distributor) · 5 pcs (repair) |
| Lead time | 15 working days after deposit |
